Magnitude |
3.2 |
| Date & Time (UTC) | 2016-08-21 16:42:57.9 |
| Date & Time (Local) | 1395/5/31 21:12:57.9 |
| Location | Lat:28.657 Lon: 51.1 |
| Region | Bushehr Province, 26 km -West of Khormog |
Nearest Cities |
|
| 12 km South of Delvar, Bushehr Province | |
| 13 km North West of Derazi, Bushehr Province | |
| 26 km North West of Khormog, Bushehr Province | |
| 27 km North West of Buheyri, Bushehr Province | |
| 29 km South West of Ahram, Bushehr Province | |
| Depth | 7 km |
| Agency | |
Faults within 150 km: |
|
| ZFF2 (Length: 84 km) , Distance to epicenter: 2 km | |
| BORAZJAN_F (Length: 168 km) , Distance to epicenter: 24 km | |
| MFF5 (Length: 74 km) , Distance to epicenter: 26 km | |
| Number of Phases | 8 |
| RMS | 0.3 |
| Number of Stations | 7 |
| Error in Latitude | 7.6 km |
| Error in Longitude | 6.2 km |
| Error in Depth | 8.3 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 108711 | IIEES | AHRM | N | 5270.4 | 0.26 | 2016-08-21 16:43:11 | 2016-08-22 04:44:00 | n |
| 108712 | IIEES | AHRM | E | 9135.2 | 0.38 | 2016-08-21 16:43:11 | 2016-08-22 04:44:00 | n |
| 108713 | IIEES | KRBR | N | 7.7 | 0.31 | 2016-08-21 16:45:19 | 2016-08-22 04:44:00 | n |
| 108714 | IIEES | KRBR | E | 7.9 | 0.16 | 2016-08-21 16:45:23 | 2016-08-22 04:44:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES | AHRM | Z | Pg | E | 2016-08-21 16:43:03 | 0.06 | y | 30.1 | 40 | |
| IIEES | AHRM | N | Sg | E | 2016-08-21 16:43:07 | -0.06 | y | 30.1 | 40 | |
| IIEES | NASN | Z | Pn | E | 2016-08-21 16:44:07 | 0.1 | y | 487 | 19 | |
| IIEES | YZKH | Z | Pn | E | 2016-08-21 16:44:13 | 0.43 | y | 532 | 38 | |
| IIEES | KRBR | Z | Pn | E | 2016-08-21 16:44:17 | -0.27 | y | 569 | 74 | |
| IIEES | KHMZ | Z | Pn | E | 2016-08-21 16:44:17 | -0.03 | y | 574 | 349 | |
| IIEES | ASAO | Z | Pn | E | 2016-08-21 16:44:28 | -0.61 | y | 661 | 351 | |
| IIEES | SNGE | Z | Pn | E | 2016-08-21 16:44:45 | 0.37 | y | 797 | 335 |
