Magnitude |
3.3 |
| Date & Time (UTC) | 2020-01-21 09:04:02.4 |
| Date & Time (Local) | 1398/11/1 12:34:02.4 |
| Location | Lat:29.17 Lon: 51.3 |
| Region | Bushehr Province, 14 km of Borazjan |
Nearest Cities |
|
| 9 km of Sarkareh, Bushehr Province | |
| 14 km of Borazjan, Bushehr Province | |
| 25 km South East of Nazar aqa, Bushehr Province | |
| 25 km South East of Ziyarat, Bushehr Province | |
| 26 km North of Bazuei, Bushehr Province | |
| Depth | 11 km |
| Agency | |
Faults within 150 km: |
|
| BORAZJAN_F (Length: 168 km) , Distance to epicenter: 11 km | |
| ZFF3 (Length: 125 km) , Distance to epicenter: 18 km | |
| ZFF2 (Length: 84 km) , Distance to epicenter: 37 km | |
| Number of Phases | 8 |
| RMS | 0.4 |
| Number of Stations | 8 |
| Error in Latitude | 4 km |
| Error in Longitude | 0 km |
| Error in Depth | 7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 151220 | IIEES SC | AHRM | Z | 770 | 1 | 2020-01-21 09:04:16 | 2020-01-22 10:56:00 | n |
| 151221 | IIEES SC | GHIR | Z | 73 | 1 | 2020-01-21 09:04:58 | 2020-01-22 10:56:00 | n |
| 151222 | IIEES SC | KLNJ | Z | 240 | 1 | 2020-01-21 09:05:08 | 2020-01-22 10:56:00 | n |
| 151223 | IIEES SC | AMIS | Z | 70 | 1 | 2020-01-21 09:05:55 | 2020-01-22 10:56:00 | n |
| 151224 | IIEES SC | GTMR | Z | 43 | 1 | 2020-01-21 09:06:27 | 2020-01-22 10:56:00 | n |
| 151225 | IIEES SC | NASN | Z | 18 | 1 | 2020-01-21 09:06:15 | 2020-01-22 10:56:00 | n |
| 151226 | IIEES SC | YZKH | Z | 15 | 1 | 2020-01-21 09:06:25 | 2020-01-22 10:56:00 | n |
| 151227 | IIEES SC | KHMZ | Z | 12 | 1 | 2020-01-21 09:06:43 | 2020-01-22 10:56:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES SC | AHRM | Z | IP | I | 2020-01-21 09:04:08 | 0 | y | 33 | 180 | |
| IIEES SC | GHIR | Z | IP | I | 2020-01-21 09:04:33 | 0.1 | y | 189 | 121 | |
| IIEES SC | KLNJ | Z | IP | I | 2020-01-21 09:04:36 | 0.3 | y | 211 | 8 | |
| IIEES SC | AMIS | Z | IP | I | 2020-01-21 09:04:53 | 0.6 | y | 333 | 325 | |
| IIEES SC | GTMR | Z | IP | I | 2020-01-21 09:05:02 | -0.6 | y | 422 | 330 | |
| IIEES SC | NASN | Z | IP | I | 2020-01-21 09:05:03 | -0.6 | y | 433 | 20 | |
| IIEES SC | YZKH | Z | IP | I | 2020-01-21 09:05:09 | -0.2 | y | 478 | 41 | |
| IIEES SC | KHMZ | Z | IP | I | 2020-01-21 09:05:13 | -1.8 | y | 522 | 346 |
