Magnitude |
3.2 |
| Date & Time (UTC) | 2020-08-25 04:41:20.7 |
| Date & Time (Local) | 1399/6/4 09:11:20.7 |
| Location | Lat:27.448 Lon: 53.632 |
| Region | Fars Province, 48 km North-East of Lamerd |
Nearest Cities |
|
| 12 km North East of Beyram, Fars Province | |
| 19 km South East of Fedagh, Fars Province | |
| 25 km North of Ashkenan, Fars Province | |
| 31 km South of Ard, Fars Province | |
| 33 km North West of Ahl, Fars Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| LAR_F (Length: 99 km) , Distance to epicenter: 34 km | |
| MFF3 (Length: 292 km) , Distance to epicenter: 42 km | |
| MFF1 (Length: 180 km) , Distance to epicenter: 58 km | |
| Number of Phases | 11 |
| RMS | 0.2 |
| Number of Stations | 11 |
| Error in Latitude | 1.6 km |
| Error in Longitude | 1.6 km |
| Error in Depth | 3 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 194628 | IIEES SC | BNDS | Z | 0.1 | 1 | 2020-08-25 04:42:28 | 2024-08-21 09:58:00 | n |
| 194629 | IIEES SC | BNDS | Z | 0.1 | 1 | 2020-08-25 04:41:59 | 2024-08-21 09:58:00 | n |
| 194630 | IIEES SC | AHRM | Z | 0.08 | 1 | 2020-08-25 04:42:02 | 2024-08-21 09:58:00 | n |
| 194631 | IIEES SC | KRBR | Z | 0.08 | 1 | 2020-08-25 04:42:20 | 2024-08-21 09:58:00 | n |
| 194632 | IIEES SC | YZKH | Z | 0.02 | 1 | 2020-08-25 04:42:37 | 2024-08-21 09:58:00 | n |
| 194633 | IIEES SC | NASN | Z | 0.01 | 1 | 2020-08-25 04:42:43 | 2024-08-21 09:58:00 | n |
| 194634 | IIEES SC | BSRN | Z | 0.01 | 1 | 2020-08-25 04:42:59 | 2024-08-21 09:58:00 | n |
| 194635 | IIEES SC | TABS | Z | 0.009 | 1 | 2020-08-25 04:43:03 | 2024-08-21 09:58:00 | n |
| 194636 | IIEES SC | KHMZ | Z | 0.02 | 1 | 2020-08-25 04:43:05 | 2024-08-21 09:58:00 | n |
| 194637 | IIEES SC | ASAO | Z | 0.01 | 1 | 2020-08-25 04:43:15 | 2024-08-21 09:58:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES SC | GHIR | Z | EPg | E | 2020-08-25 04:41:39 | 0.1 | y | 0 | 112 | 326 |
| IIEES SC | BNDS | Z | EPn | E | 2020-08-25 04:41:59 | -0.1 | y | 0 | 251 | 91 |
| IIEES SC | BNDS | Z | ES | E | 2020-08-25 04:42:28 | 0.2 | y | 0 | 251 | 91 |
| IIEES SC | AHRM | Z | EPn | E | 2020-08-25 04:42:02 | -0.1 | y | 0 | 278 | 304 |
| IIEES SC | KRBR | Z | EPn | E | 2020-08-25 04:42:20 | -0.4 | y | 0 | 415 | 47 |
| IIEES SC | YZKH | Z | EPn | E | 2020-08-25 04:42:37 | 0.1 | y | 0 | 556 | 10 |
| IIEES SC | NASN | Z | EPn | E | 2020-08-25 04:42:43 | 0.4 | y | 0 | 598 | 352 |
| IIEES SC | BSRN | Z | EPn | E | 2020-08-25 04:42:59 | -0.2 | y | 0 | 730 | 47 |
| IIEES SC | TABS | Z | EPn | E | 2020-08-25 04:43:03 | 0.1 | y | 0 | 764 | 26 |
| IIEES SC | KHMZ | Z | EPn | E | 2020-08-25 04:43:05 | -0.1 | y | 0 | 781 | 333 |
| IIEES SC | ASAO | Z | EPn | E | 2020-08-25 04:43:15 | 0.1 | y | 0 | 859 | 336 |
