Magnitude |
2.7 |
| Date & Time (UTC) | 2016-07-10 16:43:20.0 |
| Date & Time (Local) | 1395/4/20 21:13:20.0 |
| Location | Lat:33.239 Lon: 54.519 |
| Region | Esfahan Province, 113 km North-East of Ardakan |
Nearest Cities |
|
| 40 km North West of Hajiabad, Yazd Province | |
| 44 km South East of Chupanan, Esfahan Province | |
| 54 km North West of Zarrin, Yazd Province | |
| 66 km South West of Mehranjan, Esfahan Province | |
| 77 km East of Anarak, Esfahan Province | |
| Depth | 17 km |
| Agency | |
Faults within 150 km: |
|
| BIABANAK_F (Length: 162 km) , Distance to epicenter: 10 km | |
| DORUNEH_F (Length: 713 km) , Distance to epicenter: 89 km | |
| POSHT_E_BADAM_F (Length: 128 km) , Distance to epicenter: 95 km | |
| Number of Phases | 13 |
| RMS | 0.4 |
| Number of Stations | 11 |
| Error in Latitude | 3.9 km |
| Error in Longitude | 2.2 km |
| Error in Depth | 6.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 107481 | IIEES | GHVR | E | 18.9 | 0.53 | 2016-07-10 16:45:03 | 2016-07-11 06:25:00 | n |
| 107482 | IIEES | SHRO | E | 15.2 | 0.58 | 2016-07-10 16:45:03 | 2016-07-11 06:25:00 | n |
| 107483 | IIEES | SHRO | N | 13.4 | 0.54 | 2016-07-10 16:45:03 | 2016-07-11 06:25:00 | n |
| 107484 | IIEES | KRBR | E | 9.6 | 0.45 | 2016-07-10 16:45:29 | 2016-07-11 06:25:00 | n |
| 107485 | IIEES | KRBR | N | 13.1 | 0.45 | 2016-07-10 16:45:34 | 2016-07-11 06:25:00 | n |
| 107486 | IIEES | CHTH | E | 7.2 | 0.53 | 2016-07-10 16:45:26 | 2016-07-11 06:25:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES | YZKH | Z | Pg | E | 2016-07-10 16:43:36 | 0.29 | y | 94.4 | 176 | |
| IIEES | NASN | Z | Pg | E | 2016-07-10 16:43:47 | -0.35 | y | 167 | 253 | |
| IIEES | NASN | N | Sg | E | 2016-07-10 16:44:08 | -0.12 | y | 167 | 253 | |
| IIEES | TABS | Z | Pn | E | 2016-07-10 16:43:58 | 0.08 | y | 246 | 79 | |
| IIEES | TABS | E | Sg | E | 2016-07-10 16:44:29 | 0.17 | y | 246 | 79 | |
| IIEES | GHVR | Z | Pn | E | 2016-07-10 16:44:09 | 0.24 | y | 333 | 295 | |
| IIEES | SHRO | Z | Pn | E | 2016-07-10 16:44:08 | -0.35 | y | 336 | 24 | |
| IIEES | DAMV | Z | Pn | E | 2016-07-10 16:44:11 | -0.56 | y | 354 | 319 | |
| IIEES | KRBR | Z | Pn | E | 2016-07-10 16:44:19 | -0.06 | y | 419 | 149 | |
| IIEES | KHMZ | Z | Pn | E | 2016-07-10 16:44:20 | 0.28 | y | 427 | 279 | |
| IIEES | CHTH | Z | Pn | E | 2016-07-10 16:44:21 | 0.7 | y | 430 | 315 | |
| IIEES | ASAO | Z | Pn | E | 2016-07-10 16:44:22 | 0.27 | y | 440 | 290 | |
| IIEES | BSRN | Z | Pn | E | 2016-07-10 16:44:23 | -0.54 | y | 455 | 107 |
