Magnitude |
2.6 |
| Date & Time (UTC) | 2017-02-20 19:38:33.9 |
| Date & Time (Local) | 1395/12/2 23:08:33.9 |
| Location | Lat:30.791 Lon: 56.559 |
| Region | Kerman Province, 2 km of Zarand |
Nearest Cities |
|
| 2 km North of Mohammadabad, Kerman Province | |
| 2 km of Zarand, Kerman Province | |
| 10 km North of Bahaabad, Kerman Province | |
| 22 km West of Hatkan, Kerman Province | |
| 23 km North West of Khankuk, Kerman Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| KUHBANAN_F (Length: 189 km) , Distance to epicenter: 16 km | |
| DARIVAN_F (Length: 131 km) , Distance to epicenter: 31 km | |
| CHATRUD_F (Length: 37 km) , Distance to epicenter: 42 km | |
| Number of Phases | 7 |
| RMS | 0.2 |
| Number of Stations | 6 |
| Error in Latitude | 2.5 km |
| Error in Longitude | 3.4 km |
| Error in Depth | 7.6 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 113455 | IIEES | KRBR | E | 248.8 | 0.15 | 2017-02-20 19:39:02 | 2017-02-21 04:50:00 | n |
| 113456 | IIEES | KRBR | N | 236.6 | 0.15 | 2017-02-20 19:39:02 | 2017-02-21 04:50:00 | n |
| 113457 | IIEES | YZKH | E | 38.8 | 0.44 | 2017-02-20 19:39:52 | 2017-02-21 04:50:00 | n |
| 113458 | IIEES | YZKH | N | 35.7 | 0.34 | 2017-02-20 19:39:52 | 2017-02-21 04:50:00 | n |
| 113459 | IIEES | TABS | N | 11.7 | 0.56 | 2017-02-20 19:40:14 | 2017-02-21 04:50:00 | n |
| 113460 | IIEES | BNDS | E | 7.9 | 0.42 | 2017-02-20 19:40:31 | 2017-02-21 04:50:00 | n |
| 113461 | IIEES | NASN | E | 4.4 | 0.49 | 2017-02-20 19:40:37 | 2017-02-21 04:50:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES | KRBR | Z | Pg | E | 2017-02-20 19:38:49 | -0.22 | y | 91.7 | 168 | |
| IIEES | KRBR | E | Sg | E | 2017-02-20 19:39:01 | 0.22 | y | 91.7 | 168 | |
| IIEES | YZKH | Z | Pn | E | 2017-02-20 19:39:13 | -0.13 | y | 258 | 314 | |
| IIEES | BSRN | Z | Pn | E | 2017-02-20 19:39:15 | -0.07 | y | 277 | 61 | |
| IIEES | TABS | Z | Pn | E | 2017-02-20 19:39:21 | 0.18 | y | 321 | 9 | |
| IIEES | BNDS | Z | Pn | E | 2017-02-20 19:39:28 | -0.1 | y | 378 | 186 | |
| IIEES | NASN | Z | Pn | E | 2017-02-20 19:39:33 | 0.17 | y | 419 | 303 |
