Magnitude |
3.6 |
| Date & Time (UTC) | 2018-04-11 08:06:37.5 |
| Date & Time (Local) | 1397/1/22 12:36:37.5 |
| Location | Lat:31.287 Lon: 48.716 |
| Region | Khoozestan Province, 5 km of Ahvaz |
Nearest Cities |
|
| 5 km of Ahvaz, Khoozestan Province | |
| 19 km North East of Abunangeh, Khoozestan Province | |
| 20 km North East of Bahr, Khoozestan Province | |
| 24 km North West of Mashrehat, Khoozestan Province | |
| 27 km South West of Veys, Khoozestan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| AHVAZ_F (Length: 99 km) , Distance to epicenter: 6 km | |
| AGHAJARI_F (Length: 88 km) , Distance to epicenter: 50 km | |
| DEZFUL_EMBAYMENT (Length: 228 km) , Distance to epicenter: 83 km | |
| Number of Phases | 9 |
| RMS | 0.9 |
| Number of Stations | 9 |
| Error in Latitude | 9.6 km |
| Error in Longitude | 6.4 km |
| Error in Depth | 0 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 130179 | IIEES | KHMZ | E | 70.2 | 0.84 | 2018-04-11 08:08:20 | 2018-04-11 08:33:00 | n |
| 130180 | IIEES | ILBA | E | 368.7 | 0.67 | 2018-04-11 08:08:34 | 2018-04-11 08:33:00 | n |
| 130181 | IIEES | ILBA | N | 397.1 | 0.67 | 2018-04-11 08:08:36 | 2018-04-11 08:33:00 | n |
| 130182 | IIEES | AHRM | E | 36.8 | 0.5 | 2018-04-11 08:08:36 | 2018-04-11 08:33:00 | n |
| 130183 | IIEES | AHRM | N | 47 | 0.67 | 2018-04-11 08:08:38 | 2018-04-11 08:33:00 | n |
| 130184 | IIEES | ASAO | N | 129.5 | 0.92 | 2018-04-11 08:08:42 | 2018-04-11 08:33:00 | n |
| 130185 | IIEES | ASAO | E | 57.8 | 0.57 | 2018-04-11 08:08:47 | 2018-04-11 08:33:00 | n |
| 130186 | IIEES | GHVR | E | 37.7 | 0.45 | 2018-04-11 08:09:03 | 2018-04-11 08:33:00 | n |
| 130187 | IIEES | SNGE | E | 41.7 | 0.65 | 2018-04-11 08:08:56 | 2018-04-11 08:33:00 | n |
| 130188 | IIEES | SNGE | N | 30.6 | 0.37 | 2018-04-11 08:09:06 | 2018-04-11 08:33:00 | n |
| 130189 | IIEES | SRSL | E | 43.3 | 0.26 | 2018-04-11 08:09:13 | 2018-04-11 08:33:00 | n |
| 130190 | IIEES | SRSL | N | 60.3 | 0.52 | 2018-04-11 08:09:13 | 2018-04-11 08:33:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES | KHMZ | Z | Pn | E | 2018-04-11 08:07:21 | -0.21 | y | 296 | 23 | |
| IIEES | ILBA | Z | Pn | E | 2018-04-11 08:07:28 | 0.11 | y | 350 | 318 | |
| IIEES | AHRM | Z | Pn | E | 2018-04-11 08:07:28 | -1.51 | y | 366 | 137 | |
| IIEES | ASAO | Z | Pn | E | 2018-04-11 08:07:33 | 0.35 | y | 382 | 18 | |
| IIEES | NASN | Z | Pn | E | 2018-04-11 08:07:37 | -0.25 | y | 421 | 65 | |
| IIEES | GHVR | Z | Pn | E | 2018-04-11 08:07:38 | 0 | y | 426 | 33 | |
| IIEES | SNGE | Z | Pn | E | 2018-04-11 08:07:40 | -0.02 | y | 441 | 344 | |
| IIEES | GHIR | Z | Pn | E | 2018-04-11 08:07:53 | 2.18 | y | 530 | 128 | |
| IIEES | SRSL | Z | Pn | E | 2018-04-11 08:08:02 | -0.17 | y | 625 | 332 |
