Magnitude |
3 |
| Date & Time (UTC) | 2018-03-31 07:26:45.3 |
| Date & Time (Local) | 1397/1/11 11:56:45.3 |
| Location | Lat:31.92 Lon: 48.641 |
| Region | Khoozestan Province, 24 km South-West of Shushtar |
Nearest Cities |
|
| 18 km West of Sardarabad, Khoozestan Province | |
| 19 km West of Mehdiabad, Khoozestan Province | |
| 24 km South West of Shushtar, Khoozestan Province | |
| 26 km North West of Arabhasan, Khoozestan Province | |
| 27 km North East of Abdolkhan-eali, Khoozestan Province | |
| Depth | 16 km |
| Agency | |
Faults within 150 km: |
|
| DEZFUL_EMBAYMENT (Length: 228 km) , Distance to epicenter: 42 km | |
| AHVAZ_F (Length: 99 km) , Distance to epicenter: 47 km | |
| MFF2 (Length: 205 km) , Distance to epicenter: 82 km | |
| Number of Phases | 11 |
| RMS | 0.2 |
| Number of Stations | 9 |
| Error in Latitude | 7 km |
| Error in Longitude | 2.3 km |
| Error in Depth | 9.4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 131737 | IIEES | KHMZ | E | 70.9 | 0.67 | 2018-03-31 07:28:02 | 2018-05-16 07:20:00 | n |
| 131738 | IIEES | KHMZ | N | 57.8 | 0.41 | 2018-03-31 07:28:05 | 2018-05-16 07:20:00 | n |
| 131739 | IIEES | ILBA | N | 76.1 | 0.54 | 2018-03-31 07:28:15 | 2018-05-16 07:20:00 | n |
| 131740 | IIEES | ILBA | E | 69.2 | 0.7 | 2018-03-31 07:28:24 | 2018-05-16 07:20:00 | n |
| 131741 | IIEES | ASAO | N | 45.7 | 0.32 | 2018-03-31 07:28:20 | 2018-05-16 07:20:00 | n |
| 131742 | IIEES | ASAO | E | 42.2 | 0.4 | 2018-03-31 07:28:23 | 2018-05-16 07:20:00 | n |
| 131743 | IIEES | GHVR | E | 24.9 | 0.37 | 2018-03-31 07:28:39 | 2018-05-16 07:20:00 | n |
| 131744 | IIEES | GHVR | N | 12.6 | 0.49 | 2018-03-31 07:28:49 | 2018-05-16 07:20:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES | KHMZ | Z | Pn | E | 2018-03-31 07:27:22 | 0.22 | y | 237 | 31 | |
| IIEES | KHMZ | E | Sg | E | 2018-03-31 07:27:52 | 0.02 | y | 237 | 31 | |
| IIEES | ILBA | Z | Pn | E | 2018-03-31 07:27:29 | -0.12 | y | 296 | 310 | |
| IIEES | ILBA | N | Sg | E | 2018-03-31 07:28:08 | -0.02 | y | 296 | 310 | |
| IIEES | ASAO | Z | Pn | E | 2018-03-31 07:27:32 | -0.47 | y | 319 | 24 | |
| IIEES | SNGE | Z | Pn | E | 2018-03-31 07:27:39 | 0.42 | y | 372 | 341 | |
| IIEES | GHVR | Z | Pn | E | 2018-03-31 07:27:40 | 1.24 | n | 4 | 374 | 40 |
| IIEES | NASN | Z | Pn | E | 2018-03-31 07:27:43 | 0.03 | y | 404 | 75 | |
| IIEES | THKV | Z | Pn | E | 2018-03-31 07:27:53 | -0.15 | y | 489 | 24 | |
| IIEES | CHTH | Z | Pn | E | 2018-03-31 07:27:54 | 0.02 | y | 498 | 27 | |
| IIEES | TABS | Z | Pn | E | 2018-03-31 07:28:34 | 0.09 | y | 817 | 74 |
