Magnitude |
3.3 |
| Date & Time (UTC) | 2020-03-06 23:04:01.5 |
| Date & Time (Local) | 1398/12/17 02:34:01.5 |
| Location | Lat:31.01 Lon: 50.14 |
| Region | Kohkiluieh va boyerahmad Province, 47 km North-West of Behbahan |
Nearest Cities |
|
| 27 km North West of Lendeh, Kohkiluieh va boyerahmad Province | |
| 31 km North East of Jolaki, Khoozestan Province | |
| 32 km North East of Jayzan, Khoozestan Province | |
| 33 km South West of Esfandan, Kohkiluieh va boyerahmad Province | |
| 33 km North of Dodange-ye bozorg, Khoozestan Province | |
| Depth | 10 km |
| Agency | |
Faults within 150 km: |
|
| MFF4 (Length: 62 km) , Distance to epicenter: 1 km | |
| MFF2 (Length: 205 km) , Distance to epicenter: 31 km | |
| DEZFUL_EMBAYMENT (Length: 228 km) , Distance to epicenter: 37 km | |
| Number of Phases | 10 |
| RMS | 0.3 |
| Number of Stations | 10 |
| Error in Latitude | 6 km |
| Error in Longitude | 0 km |
| Error in Depth | 10 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 152313 | IIEES SC | AMIS | Z | 670 | 1 | 2020-03-06 23:04:40 | 2020-03-09 08:31:00 | n |
| 152314 | IIEES SC | KLNJ | Z | 500 | 1 | 2020-03-06 23:04:54 | 2020-03-09 08:31:00 | n |
| 152315 | IIEES SC | GTMR | Z | 260 | 1 | 2020-03-06 23:05:03 | 2020-03-09 08:31:00 | n |
| 152316 | IIEES SC | KHMZ | Z | 35 | 1 | 2020-03-06 23:05:32 | 2020-03-09 08:31:00 | n |
| 152317 | IIEES SC | NASN | Z | 23 | 1 | 2020-03-06 23:05:50 | 2020-03-09 08:31:00 | n |
| 152318 | IIEES SC | ASAO | Z | 32 | 1 | 2020-03-06 23:06:09 | 2020-03-09 08:31:00 | n |
| 152319 | IIEES SC | GHVR | Z | 430 | 1 | 2020-03-06 23:06:30 | 2020-03-09 08:31:00 | n |
| 152320 | IIEES SC | YZKH | Z | 12 | 1 | 2020-03-06 23:05:52 | 2020-03-09 08:31:00 | n |
| 152321 | IIEES SC | SNGE | Z | 14 | 1 | 2020-03-06 23:06:33 | 2020-03-09 08:31:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES SC | AMIS | Z | IP | I | 2020-03-06 23:04:20 | 0.1 | y | 111 | 312 | |
| IIEES SC | KLNJ | Z | IP | I | 2020-03-06 23:04:24 | -0.1 | y | 133 | 90 | |
| IIEES SC | GTMR | Z | IP | I | 2020-03-06 23:04:32 | -0.3 | y | 189 | 329 | |
| IIEES SC | KHMZ | Z | IP | I | 2020-03-06 23:04:47 | -0.3 | y | 300 | 357 | |
| IIEES SC | NASN | Z | IP | I | 2020-03-06 23:04:49 | 0 | y | 322 | 52 | |
| IIEES SC | ASAO | Z | IP | I | 2020-03-06 23:04:58 | 0.3 | y | 389 | 358 | |
| IIEES SC | GHVR | Z | IP | I | 2020-03-06 23:05:00 | 0.8 | y | 400 | 15 | |
| IIEES SC | YZKH | Z | IP | I | 2020-03-06 23:05:05 | 0 | y | 444 | 70 | |
| IIEES SC | SNGE | Z | IP | I | 2020-03-06 23:05:15 | 0.9 | y | 522 | 330 | |
| IIEES SC | QABG | Z | IP | I | 2020-03-06 23:05:14 | -0.7 | y | 522 | 354 |
