Magnitude |
3.5 |
| Date & Time (UTC) | 2022-06-16 04:14:16.6 |
| Date & Time (Local) | 1401/3/26 08:44:16.6 |
| Location | Lat:26.645 Lon: 54.332 |
| Region | Persian Gulf, 62 km South of Bastak |
Nearest Cities |
|
| 42 km South of Jenah, Hormozgan Province | |
| 53 km North West of Bandar-e lengeh, Hormozgan Province | |
| 62 km South of Bastak, Hormozgan Province | |
| 83 km South East of Ahl, Fars Province | |
| 96 km South East of Ashkenan, Fars Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| ZFF1 (Length: 165 km) , Distance to epicenter: 11 km | |
| MFF3 (Length: 292 km) , Distance to epicenter: 36 km | |
| MFF1 (Length: 180 km) , Distance to epicenter: 48 km | |
| Number of Phases | 12 |
| RMS | 0.5 |
| Number of Stations | 12 |
| Error in Latitude | 3.5 km |
| Error in Longitude | 3.5 km |
| Error in Depth | 557.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 171310 | IIEES SC | AHRM | Z | 0.07 | 1 | 2022-06-16 04:15:14 | 2022-06-18 04:02:00 | n |
| 171311 | IIEES SC | KRBR | Z | 0.1 | 1 | 2022-06-16 04:15:20 | 2022-06-18 04:02:00 | n |
| 171312 | IIEES SC | KLNJ | Z | 0.06 | 1 | 2022-06-16 04:15:33 | 2022-06-18 04:02:00 | n |
| 171313 | IIEES SC | NASN | Z | 0.02 | 1 | 2022-06-16 04:15:50 | 2022-06-18 04:02:00 | n |
| 171314 | IIEES SC | BSRN | Z | 0.01 | 1 | 2022-06-16 04:15:57 | 2022-06-18 04:02:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES SC | GHIR | Z | EPn | E | 2022-06-16 04:14:52 | -0.3 | y | 0 | 225 | 324 |
| IIEES SC | JSSH | Z | EPn | E | 2022-06-16 04:15:03 | -0.1 | y | 0 | 316 | 105 |
| IIEES SC | AHRM | Z | EPn | E | 2022-06-16 04:15:14 | 0.7 | y | 0 | 400 | 308 |
| IIEES SC | KRBR | Z | EPn | E | 2022-06-16 04:15:20 | 0.8 | y | 0 | 440 | 33 |
| IIEES SC | MEH | Z | EPn | E | 2022-06-16 04:15:30 | 0.5 | y | 0 | 527 | 3 |
| IIEES SC | KLNJ | Z | EPn | E | 2022-06-16 04:15:33 | -0.4 | y | 0 | 553 | 331 |
| IIEES SC | YZKH | Z | EPn | E | 2022-06-16 04:15:14 | -29.9 | n | 4 | 637 | 2 |
| IIEES SC | NASN | Z | EPn | E | 2022-06-16 04:15:50 | -0.6 | y | 0 | 698 | 348 |
| IIEES SC | ZHSF | Z | EPn | E | 2022-06-16 04:15:52 | -0.2 | y | 0 | 712 | 63 |
| IIEES SC | BSRN | Z | EPn | E | 2022-06-16 04:15:57 | -0.2 | y | 0 | 751 | 38 |
| IIEES SC | SRVN | Z | EPn | E | 2022-06-16 04:16:04 | -0.3 | y | 0 | 805 | 84 |
| IIEES SC | SHRT | Z | EPn | E | 2022-06-16 04:16:24 | 0.2 | y | 0 | 965 | 36 |
