Magnitude |
3.5 |
| Date & Time (UTC) | 2022-07-25 23:39:51.2 |
| Date & Time (Local) | 1401/5/4 04:09:51.2 |
| Location | Lat:31.291 Lon: 56.431 |
| Region | Kerman Province, 36 km -West of Ravar |
Nearest Cities |
|
| 16 km North of Toghroljerd, Kerman Province | |
| 16 km East of Jor, Kerman Province | |
| 19 km South East of Kuhbanan, Kerman Province | |
| 29 km North West of Dasht-e khak, Kerman Province | |
| 35 km West of Dehali, Kerman Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| KUHBANAN_F (Length: 189 km) , Distance to epicenter: 16 km | |
| JAFARABAD_F (Length: 60 km) , Distance to epicenter: 49 km | |
| LAKARKUH_F (Length: 138 km) , Distance to epicenter: 62 km | |
| Number of Phases | 11 |
| RMS | 0.3 |
| Number of Stations | 11 |
| Error in Latitude | 2.5 km |
| Error in Longitude | 2.5 km |
| Error in Depth | 15.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
|---|---|---|---|---|---|---|---|---|
| 173309 | IIEES SC | KRBR | Z | 1 | 1 | 2022-07-25 23:40:15 | 2022-09-06 05:23:00 | n |
| 173310 | IIEES SC | YZKH | Z | 1 | 1 | 2022-07-25 23:40:25 | 2022-09-06 05:23:00 | n |
| 173311 | IIEES SC | BSRN | Z | 0.3 | 1 | 2022-07-25 23:40:32 | 2022-09-06 05:23:00 | n |
| 173312 | IIEES SC | TABS | Z | 0.4 | 1 | 2022-07-25 23:40:32 | 2022-09-06 05:23:00 | n |
| 173313 | IIEES SC | SHRT | Z | 0.09 | 1 | 2022-07-25 23:40:55 | 2022-09-06 05:23:00 | n |
| 173314 | IIEES SC | TBJM | Z | 0.09 | 1 | 2022-07-25 23:41:10 | 2022-09-06 05:23:00 | n |
| 173315 | IIEES SC | MRVT | Z | 0.01 | 1 | 2022-07-25 23:41:26 | 2022-09-06 05:23:00 | n |
| 173316 | IIEES SC | BJRD | Z | 0.009 | 1 | 2022-07-25 23:41:26 | 2022-09-06 05:23:00 | n |
Phase
| Agency | Station | Component | Phase Type | Phase Quality | Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth |
|---|---|---|---|---|---|---|---|---|---|---|
| IIEES SC | KRBR | Z | EPg | E | 2022-07-25 23:40:15 | -0.1 | y | 0 | 148 | 168 |
| IIEES SC | YZKH | Z | EPn | E | 2022-07-25 23:40:25 | 0 | y | 0 | 212 | 305 |
| IIEES SC | BSRN | Z | EPn | E | 2022-07-25 23:40:32 | -0.4 | y | 0 | 266 | 74 |
| IIEES SC | TABS | Z | EPn | E | 2022-07-25 23:40:32 | -0.2 | y | 0 | 269 | 14 |
| IIEES SC | SHRT | Z | EPn | E | 2022-07-25 23:40:55 | 0.5 | y | 0 | 447 | 54 |
| IIEES SC | ZHSF | Z | EPn | E | 2022-07-25 23:40:56 | 0.6 | y | 0 | 456 | 114 |
| IIEES SC | KLNJ | Z | EPn | E | 2022-07-25 23:40:22 | -34.7 | n | 4 | 462 | 266 |
| IIEES SC | SHRO | Z | EPn | E | 2022-07-25 23:40:57 | -7.2 | n | 4 | 525 | 356 |
| IIEES SC | TBJM | Z | EPn | E | 2022-07-25 23:41:10 | 0.4 | y | 0 | 571 | 39 |
| IIEES SC | MRVT | Z | EPn | E | 2022-07-25 23:41:26 | -0.1 | y | 0 | 707 | 357 |
| IIEES SC | BJRD | Z | EPn | E | 2022-07-25 23:41:26 | -1.9 | y | 0 | 717 | 7 |
