Date & Time (UTC) 2023-02-25 00:09:40.0
Date & Time (Local) 1401/12/6  03:39:40.0
Location Lat:36.204 Lon: 43.491
Region Iraq
Nearest Cities
158 km South West of Piranshahr, Azarbaijan Gharbi Province
159 km South West of Silveh, Azarbaijan Gharbi Province
160 km South West of Chiyaneh, Azarbaijan Gharbi Province
162 km South West of Kavir, Azarbaijan Gharbi Province
169 km South West of Mirabad, Azarbaijan Gharbi Province
Depth 12 km
Faults within 150 km:
PIRANSHAHR_F (Length: 253 km) , Distance to epicenter: 145 km
Number of Phases 20
RMS 0.3
Number of Stations 20
Error in Latitude >1.4 km
Error in Longitude 1.4 km
Error in Depth 7 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here


UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
179384IIEES SCSRSLZ 512023-02-25 00:10:082023-02-25 05:48:00n
179385IIEES SCSRSLZ 512023-02-25 00:10:292023-02-25 05:48:00n
179386IIEES SCGUROZ 0.312023-02-25 00:10:242023-02-25 05:48:00n
179387IIEES SCMRDZ 0.412023-02-25 00:10:302023-02-25 05:48:00n
179388IIEES SCILBAZ 0.112023-02-25 00:10:342023-02-25 05:48:00n
179389IIEES SCGNIZ 0.0912023-02-25 00:10:442023-02-25 05:48:00n
179390IIEES SCZNJKZ 0.0812023-02-25 00:10:472023-02-25 05:48:00n
179391IIEES SCGRMIZ 0.0512023-02-25 00:10:482023-02-25 05:48:00n
179392IIEES SCASAOZ 0.0412023-02-25 00:11:052023-02-25 05:48:00n
179393IIEES SCGTMRZ 0.112023-02-25 00:11:092023-02-25 05:48:00n


AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEES SCSRSLZ EPg E2023-02-25 00:10:080.3y017590
IIEES SCSRSLZ ESg E2023-02-25 00:10:290.2y017590
IIEES SCMAHBZ EPn E2023-02-25 00:10:13-0.6y020873
IIEES SCMAHBZ ES E2023-02-25 00:10:38-0.2y020873
IIEES SCAZRZ EPn E2023-02-25 00:10:220y027654
IIEES SCGUROZ EPn E2023-02-25 00:10:240.3y0291334
IIEES SCDHRZ EPn E2023-02-25 00:10:26-0.1y0311122
IIEES SCMRDZ EPn E2023-02-25 00:10:300.2y034035
IIEES SCMAKUZ EPn E2023-02-25 00:10:32-0.7y036517
IIEES SCSNGEZ EPn E2023-02-25 00:10:34-0.1y0370109
IIEES SCILBAZ EPn E2023-02-25 00:10:34-0.1y0379139
IIEES SCKCHFZ EPn E2023-02-25 00:10:36-0.1y0388124
IIEES SCGNIZ EPn E2023-02-25 00:10:440y045114
IIEES SCZNJKZ EPn E2023-02-25 00:10:470.8y046984
IIEES SCGRMIZ EPn E2023-02-25 00:10:48-0.1y048553
IIEES SCHGHAZ EPn E2023-02-25 00:10:490.7y049199
IIEES SCARPRZ EPn E2023-02-25 00:10:592.3n4557305
IIEES SCGIDEZ EPn E2023-02-25 00:10:59-0.1y057382
IIEES SCASAOZ EPn E2023-02-25 00:11:050.3y0622107
IIEES SCGTMRZ EPn E2023-02-25 00:11:09-1.1y0663129
