Magnitude
 :3.6
Date & Time (UTC) 2022-10-13 05:56:27.0
Date & Time (Local) 1401/7/21  09:26:27.0
Location Lat:37.261 Lon: 57.55
Region Khorasan(north) Province, 23 km North of Esfarayen
Nearest Cities
17 km West of Zavarom, Khorasan(north) Province
20 km North East of Eraj, Khorasan(north) Province
22 km North of Parkanlu, Khorasan(north) Province
23 km North of Esfarayen, Khorasan(north) Province
29 km South of Hesar-egarmkhanh, Khorasan(north) Province
Depth 12 km
Agency
Faults within 150 km:
ESFARAYEN_F (Length: 111 km) , Distance to epicenter: 19 km
ROBATE_QARABIL_F (Length: 168 km) , Distance to epicenter: 49 km
BAGHAN_GERMAB_F (Length: 79 km) , Distance to epicenter: 53 km
Number of Phases 13
RMS 0.5
Number of Stations 13
Error in Latitude >3 km
Error in Longitude 3 km
Error in Depth 6.4 km

Download waveform in seisan format

to download seisan software Click here

to access information about IIEES stations Click here

Amplitude

UIDAgencyStationComponentAmplitudePeriodArrival TimeProccessing TimeSignal Clip
174266IIEES SCQUCHZ 1012022-10-13 05:56:412022-10-15 05:31:00n
174267IIEES SCMRVTZ 0.712022-10-13 05:56:492022-10-15 05:31:00n
174268IIEES SCKAGHZ 0.212022-10-13 05:57:022022-10-15 05:31:00n
174269IIEES SCABGHZ 112022-10-13 05:57:062022-10-15 05:31:00n
174270IIEES SCJRKHZ 0.812022-10-13 05:57:102022-10-15 05:31:00n
174271IIEES SCTBJMZ 0.312022-10-13 05:57:172022-10-15 05:31:00n
174272IIEES SCKKHKZ 0.212022-10-13 05:57:192022-10-15 05:31:00n
174273IIEES SCTABSZ 0.212022-10-13 05:57:242022-10-15 05:31:00n
174274IIEES SCSHRTZ 0.0612022-10-13 05:57:332022-10-15 05:31:00n
174275IIEES SCYZKHZ 0.0612022-10-13 05:57:492022-10-15 05:31:00n

Phase

AgencyStationComponentPhase TypePhase QualityFirst MotionObserved Arrival TimeTime ResidualLoc. FlagInput WeightDistanceAzimuth
IIEES SCBJRDZ EPg E2022-10-13 05:56:35-0.1y050346
IIEES SCQUCHZ EPg E2022-10-13 05:56:410y085107
IIEES SCMRVTZ EPg E2022-10-13 05:56:49-0.2y0137289
IIEES SCSHROZ EPg E2022-10-13 05:56:37-21.3n4196225
IIEES SCKAGHZ EPn E2022-10-13 05:57:020.7y021799
IIEES SCABGHZ EPn E2022-10-13 05:57:060.5y0252257
IIEES SCJRKHZ EPn E2022-10-13 05:57:10-0.3y0292121
IIEES SCTBJMZ EPn E2022-10-13 05:57:170.8y0334132
IIEES SCGLOZ EPn E2022-10-13 05:57:180.7y0342256
IIEES SCKKHKZ EPn E2022-10-13 05:57:19-0.8y0360164
IIEES SCTABSZ EPn E2022-10-13 05:57:24-0.1y0403186
IIEES SCSHRTZ EPn E2022-10-13 05:57:33-0.5y0472148
IIEES SCYZKHZ EPn E2022-10-13 05:57:49-0.6y0604207
