Magnitude |
:3 |
| Date & Time (UTC) | 2023-01-19 20:10:23.8 |
| Date & Time (Local) | 1401/10/29 23:40:23.8 |
| Location | Lat:38.627 Lon: 44.907 |
| Region | Azarbaijan Gharbi Province, 9 km of Khoy |
Nearest Cities |
|
| 5 km of Dizaj, Azarbaijan Gharbi Province | |
| 9 km North of Khoy, Azarbaijan Gharbi Province | |
| 12 km North West of Saeedabad, Azarbaijan Gharbi Province | |
| 13 km North East of Beyk sofla, Azarbaijan Gharbi Province | |
| 20 km North of Quruq, Azarbaijan Gharbi Province | |
| Depth | 10 km |
| Agency | |
Faults within 150 km: |
|
| KHOY (Length: 100 km) , Distance to epicenter: 6 km | |
| N_TABRIZ_F3 (Length: 66 km) , Distance to epicenter: 36 km | |
| N_TABRIZ_F1 (Length: 222 km) , Distance to epicenter: 42 km | |
| Number of Phases | 11 |
| RMS | 0.6 |
| Number of Stations | 11 |
| Error in Latitude | >3.5 km |
| Error in Longitude | 3.5 km |
| Error in Depth | 9.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 177885 | IIEES SC | GNI | Z | 0.4 | 1 | 2023-01-19 20:10:51 | 2023-01-21 11:13:00 | n |
| 177886 | IIEES SC | DHR | Z | 0.03 | 1 | 2023-01-19 20:11:27 | 2023-01-21 11:13:00 | n |
| 177887 | IIEES SC | HGHA | Z | 0.01 | 1 | 2023-01-19 20:11:33 | 2023-01-21 11:13:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | MRD | Z | EPg | E | 2023-01-19 20:10:36 | 0.3 | y | 0 | 70 | 82 | ||
| IIEES SC | MAKU | Z | EPg | E | 2023-01-19 20:10:37 | -0.8 | y | 0 | 83 | 347 | ||
| IIEES SC | GNI | Z | EPg | E | 2023-01-19 20:10:51 | -0.1 | y | 0 | 170 | 355 | ||
| IIEES SC | MAHB | Z | EPn | E | 2023-01-19 20:10:58 | -0.9 | y | 0 | 218 | 161 | ||
| IIEES SC | GURO | Z | EPn | E | 2023-01-19 20:11:03 | 0.5 | y | 0 | 251 | 268 | ||
| IIEES SC | GRMI | Z | EPn | E | 2023-01-19 20:11:05 | 0.7 | y | 0 | 261 | 86 | ||
| IIEES SC | SRSL | Z | EPn | E | 2023-01-19 20:11:04 | -0.9 | y | 0 | 272 | 170 | ||
| IIEES SC | BGD | Z | EPn | E | 2023-01-19 20:11:15 | 4.5 | n | 4 | 314 | 339 | ||
| IIEES SC | DHR | Z | EPn | E | 2023-01-19 20:11:27 | -0.8 | y | 0 | 455 | 163 | ||
| IIEES SC | GIDE | Z | EPn | E | 2023-01-19 20:11:31 | 0.8 | y | 0 | 473 | 114 | ||
| IIEES SC | HGHA | Z | EPn | E | 2023-01-19 20:11:33 | -0.2 | y | 0 | 495 | 135 | ||
